Main screen

  1. : Indicates that dash cam is in normal recording. In case of abnormal recording, the red dot disappears and   displays.
  2. : Indicates that the location information has been obtained.
  3. : Indicates that Wi-Fi hotspot is enabled.
  4. : Indicates that motion detection or collision detection function is enabled.
  5. : Indicates that time-lapse photography function is enabled.
  6.   : Indicates that ADAS has successfully calibrated. During the calibration, icon   displays and icon replaces if calibration fails.

When dash cam is connected with the app, the main screen displays the following image.


Note: Illustrations of the product, accessories, and user interface in the user manual and user guide are for reference purposes only. The actual product and functions may vary due to product enhancements.

Button functions

Power button

  • Press the power button to turn on the dash cam (Dash cam should be connected with external power source).
  • Press and hold the power button to turn off the dash cam.
  • Press and hold the power button for about 15 seconds to force shutdown.
  • In the power-on status, press the power button to turn off/light up the screen.
  • Press on other pages to select and confirm.

Upper button

  • Press on the home screen to switch to the bottom of the quick control panel.
  • Press on other pages to switch to the previous option.

Lower button

  • Press on the home screen to switch to the head of the quick control panel.
  • Press on other pages to switch to the next option.

Indicator light

Dash cam statusIndicator description
1. Off
2. Recording normally		Off
1. In waiting mode⓵
2. Connected to the app
3. 4G module successfully connects with the Internet.		Blue light
1. Recording emergency video.
2. Severe system error occurs.
3. Remotely control the dash cam to record video.		Red light
1. Dash cam fails to obtain location information.
2. 4G module disconnects with the Internet.		Yellow light

⓵ Dash cam is in waiting mode in the following situations:

  • Waiting for activation when dash cam is turned on for the first time.
  • Updating firmware
  • Formatting the internal memory
  • Restoring factory settings
